Research on Temperature Field of the Support Structure for the Independent LNG Tank

Authors

  • Shifeng Ding School of Naval Architecture and Ocean Engineering, Jiangsu University of Science and Technology, Zhenjiang,Jiangsu, 212003, China
  • Li Zhou School of Naval Architecture and Ocean Engineering, Jiangsu University of Science and Technology, Zhenjiang,Jiangsu, 212003, China
  • Yajun Zhou Shanghai Rules and Research Institute, China Classification Society, Shanghai, 200135, China
  • Yingjie Gu School of Naval Architecture and Ocean Engineering, Jiangsu University of Science and Technology, Zhenjiang,Jiangsu, 212003, China
  • Vladimir G. Tsuprik School of Engineering, Far Eastern Federal University, Vladivostok, Primorskyi krai, Russia

DOI:

https://doi.org/10.30564/hsme.v2i1.1690

Abstract

The independent LNG (Liquified Nature Gas) containment is widely used for small or medium-sized LNG carrier and ship using LNG as fuels. The common tank pattern includes single-spherical-cylindrical tank and double-spherical-cylindrical tank, which is the key to design the hull structure and its support. The support is designed to connect the hull structure and LNG tank. Its main functions are heat transferring and force loading. This paper focus on the temperature field distribution of hull and its support structure. The thermal boundary conditions are simulated according to the heat transfer action, such as thermal convection, heat conduction and thermal radiation. The method on how to carry out thermal analysis is presented for an independent LNG containment. The case study is carried out with two typical independent LNG tanks. One is a tank with double spherical cylindrical in the LNG carrier, and the other is a tank with single spherical cylindrical on the deck of the ship using LNG as fuels. The result shows the method presented in this paper is a good reference for the structural design with independent LNG containment.

Keywords:

Temperature filed; Heat transfer analysis; Thermal convection; Support structure; Independent LNG carrier

References

[1] M. H. Jin, K. J. Xu, S. M. Cheng, et al. Calculation of static daily evaporation rate for large LNG storage tanks. Oil & Gas Storage and Transportation, 2016, 35(4): 386-390.

[2] Kurle Y. M., S. Wang, Q. Xu. Simulation study on boil-off gas minimization and recovery strategies at LNG exporting terminals. Applied Energy, 2015, 156(1): 628-641.

[3] L. Wang, Z. Chen, H. Meng. Numerical study of conjugate heat transfer of cryogenic methane in rectangular engine cooling channels at supercritical pressures. Applied Thermal Engineering, 2013, 54(1): 237-246.

[4] Prokes L., Hegrova J., Kanicky V.. Analysis of means (ANOM) as a tool for comparison of sample treatment methods: testing various mineralization procedures for selenium determination in biological materials. Journal of Aoac International, 2017, 100(1): 236-240.

[5] S. B. Chang, H.P. Choong, G.L. Dai. Optimum glass fiber volume fraction in the adhesive for the AI-SUS adhesively bonded joints at cryogenic temperatures.Composite Structures, 2014, 108: 119-128.

[6] Sung W. C., Han S. K., Woo Il Lee. Analysis of leaked LNG flow and consequent thermal effect for safety. Ocean Engineering, 2016, 113: 276-294.

[7] J. F. Liu, J.Y. Wang, T. Liu. Temperature Field Distribution of LNG Carrier for Type B Independent Tank. Ship Engineering, 2017, 39(4): 33-38.

[8] Jiang J. Che C. D., Lu S.. Temperature Field Analysis for Type C LNG Carrier’s Cargo Hold. Naval Architecture and Ocean Engineering, 2018, 34(5): 9-14.

[9] C.Z. Ma, W.Y. Tang. Research on the Temperature Field of SPB Type LNG Carrier. Naval Architecture and Ocean Engineering, 2017, 33(5): 28-34.

[10] Z. C. Li, B.L. Guo, J.W. Yan. Calculation and influencing factors of temperature field in LNG tank. Oil & Gas Storage and Transportation, 2015, 34(3): 244-247.

[11] Q. Q. Zeng. Temperature Field Calculation for Cargo Hold of Small and Medium LNG Carrier. Guangdong Shipbuilding, 2017, 3: 44-46.

[12] Roh S., Son G, Song G., et al. Numerical study of transient natural convection in a pressurized LNG storage tank. Applied Thermal Engineering, 2013, 52(1): 209-220.

[13] TGE. Temperature Distribution Cargo Hold 30000m3 LNG-Carrier, 2013.

[14] ABS. Guide for Building and Classing Liquefied Gas Carriers with Independent Tanks, 2010.

[15] USCG. Safety standards for self-propelled vessels carrying bulk liquefied gases, 2012.

[16] IACS. Common structural rules for bulk carriers and oil tankers, 2018.
