Mathematical Model to Estimate Carbon Footprint for EEG Incubation

Authors

  • Tarek Fouda Faculty of Agriculture, Agricultural Engineering Department, Tanta University, Egypt
  • Nourhan KASSAB Faculty of Agriculture, Agricultural Engineering Department, Tanta University, Egypt

DOI:

https://doi.org/10.30564/jzr.v2i3.2109

Abstract

This work presents a performance comparison between several incubators models including CO2, and NH4 emission. A mathematical model for incubators carbon foot print was developed to estimate CO2, Nh4 emission. The program written by C++ language including convert line. The modular structure of program consists of a main programme and series of independent subroutine، each one deals with a specific parameter of the required data. The computer programme has a wide range of applicability several values of size of the machine (NO. egg), Fertility (F), Heat production embryo (HPe), maximum CO2 level (CO2)m , CO2 level incoming air (CO2)I ,RQ value (RQ) to estimate  Heat production (HP( , CO2 production  , Ventilation (V) , Ventilation of egg (Vegg) Input data: Enter size of the machine, Fertility (F), Heat production embryo (HPe), maximum CO2 level (CO2)m , CO2 level incoming air (CO2)I ,RQ value (RQ) the results As the growth period passed from the first day of the twenty-first day, the amount of heat produced increased from 0.0001 to 0.35 w / egg , and ventilation from 0 to 352 m3 / hr as well as the amount of carbon dioxide produced from 0.0000158 to 0.04318 lit/hr/Mach . As the number of eggs increased from 5,000 to 30,000 eggs, each of the heat produced increased from 923.4 to 5540.4 kg / hr, the resulting carbon dioxide from 32 to 190 lit / hr / Mach, and ventilation from 9 to 54 m3/hr



Keywords:

Carbon; Ammonia; Incubator; Poultry housing; Model and hens

References

[1] Calvet, S., Cambra-Lopez, M., Estelles, F. and Torres, A.G. (2011). Characterization of gas emissions from a Mediterranean broiler farm. Poult. Sci., 90.. 534–542. DOI: 10.3382/ps.2010-01037.

[2] Everaert, N., Willemsen, H., Kamers, B.et al., (2011). Regulatory capacities of a broiler and layer strain exposed to high CO2 levels during the second half of incubation. Comp Biochem Physiol A Mol Integr Physiol 158(2): 215-220.

[3] Fernandes, J., Bortoluzzi, C., Esser, AFG., Contini, JP., Stokler, PB. and Faust, D. (2014). Performance of broilers submitted to high CO2 levels during incubation combined with temperature fluctuations at late pot-hatch. Brazilian Journal of Poultry Science ;16(3):285-290.

[4] Ferner, K. & Mortola, J. P. (2009). Ventilatory response to hypoxia in chicken hatchlings: a developmental window of sensitivity to embryonic hypoxia. Respir Physiol Neurobiol 165(1): 49-53.

[5] Hulzebosch, J., (2004). What affects the climate in poultry houses?. World Poultry. 20.. 36-38.

[6] International Organization for Standardization (ISO), (2006). ISO 14040: Environmental management – Life Cycle Assessment – Principles and framework. International Organization for Standardization, Geneva. www.iso.org.

[7] Mortola, J. P. (2009). Gas exchange in avian embryos and hatchlings. Comp Biochem Physiol A Mol Integr Physiol. 153(4): 359-377.

[8] Toit DU, C.J.L., VAN Niekerk, W.A., Meissner, H.H. (2013). Direct methane and nitrous oxide emissions of monogastric livestock in South Africa. South African Journal of Animal Science 43, 362.

[9] Tona, K., Onagbesan, O., Bruggeman, V., De Smit, L., Figueiredo, D. and Decuypere, E. (2007). Non-ventilation during early incubation in combination with dexamethasone administration during late incubation 1. Effects on physiological hormone levels, incubation duration and hatching events. Domest. Anim. Endocrinol., 33 , pp. 32-46

[10] Walker, J.T., Robarge, W.P., and Austin R. (2014). Modeling of ammonia dry deposition to a pocosin landscape downwind of a large poultry facility. Agriculture, Ecosystems and Environment, 185.. 161–175. DOI: 10.1016/j. agee.2013.10.029.

Downloads

Issue

Vol. 2 , Iss. 3 (July 2020)

Article Type

Articles
