Investigation of the Mechanical Properties of Flexible Polyether Foam Filled with Eggshell and Groundnut Husk Powder

Authors

  • Pauline Uchechukwu Chris-Okafor Department of Pure and Industrial Chemistry, Faculty of Physical Sciences, NnamdiAzikiwe UniversityAwka, Anambra State, Nigeria
  • Rosemary Arinze Department of Pure and Industrial Chemistry, Faculty of Physical Sciences, NnamdiAzikiwe UniversityAwka, Anambra State, Nigeria
  • I.M. Iloamaeke Department of Pure and Industrial Chemistry, Faculty of Physical Sciences, NnamdiAzikiwe UniversityAwka, Anambra State, Nigeria
  • B. C. Izundu Department of Pure and Industrial Chemistry, Faculty of Physical Sciences, NnamdiAzikiwe UniversityAwka, Anambra State, Nigeria

DOI:

https://doi.org/10.30564/opmr.v1i2.1641

Abstract

The study investigated the effect of eggshell and groundnut husk as fillers on flexible polyether foam. The fillers with the particle sizes of 50µm each were mixed in the ratio of 50:50. Diverse percentages of the two combined fillers ranging from 10%, 20%, 30%, 40% and 50% were incorporated into the polyether recipes in the appropriate foam formulations and foam samples were produced. The unfilled foam (0%filler) served as the standard control sample. The physico-mechanical test carried out on the foam showed increase in the properties such as density, compression set test, indentation hardness test, tensile strength test and decrease for elongation at break test as compared to the unfilled foam. The scanning electron microscopy result showed the cell sizes became smaller and concentrated with an irregular shape as the filler load increased, thereby making it denser and thicker. Eggshell and groundnut husk fillers may be used in the making of flexible polyether foam since these materials are organic in natures. They can improve the mechanical properties and biodegradability of polyurethane product. The utilization of these fillers in polymer composites productin will help in sanitizing the environment by reducing landfills and producing eco-friendly waste and also it influences cost positively.

Keywords:

Egg shell; groundnut husk; polyether foam; Scanning electron microscope; Mechanical properties.

References

[1] Kugler, P.M., Wiltz, E.P., Wuilay, H.. A New Era for MDI Flexible Polyurethane Slab Stock Foam,Cellular plastic, 1997, 33(2): 159-184.

[2] Usman, M.A., Adesosun, S.O., Osifeso, G.O.. Optimum Calcium Filler Concentration for Flexible Polyurethane Foam Composite, A Journal of Materials and Materials Characterization Engineering, 2012, 11(3): 311-320.

[3] Klempner, D., Sendijaveric, V.. Handbook of Polymeric Foams and Foam. Technology.Hanser Publishers. Munich, 2004: 339-378.

[4] Onuegbu, T.U., Obianuko, N., Mbachu, G.U., Iloamaeke, I.M.. Effects of Animal Waste (Goat Femur) as a Filler in Flexible Polyether Foam, Journal of Basic Physical Research, 2010, 1(1): 5-8.

[5] Ajiwe, V. I. E, Ulakpa, C. M, Onuegbu, T. U.. Additive Effects On Production of Polyurethane Flexible Foams,World Journal of Biotechnology,2005, 6(1): 957-967.

[6] Hans, G.E.. Plastics, General Survey in Ullmann’s Encyclopedia Industrial Chemistry, Willey, VCH, Weinhein, 2005.

[7] Toro, P., Quijad, R., Yazdani-Pedram, M., Arias,J.L.. Eggshell, a New Bio-Filler for Polypropylene Composites, Materials letters, 2007, 61(22): 4347-4350.

[8] Abdullah, A.S.. Water adsorption mechanical properties of high density polyethylene/egg shell composite, Journal of Basrah Researches (Sciences), 2011, 37(3): 36-42.

[9] Vitafoam Plc Nigeria; Manual Guide.

[10] Saliba, C.C., Orefice, R.L., Carneiro, J.R.G., Duarte A.K., Schneider, W.T., Fernandez, M.R.F.. Effect of the Incorporation of a Novel Natural Inorganic Short Fibre on the Properties of Polyurethane Composites; Polymer Test, 2005, 24(7): 819-824.

[11] Dalen, M.B., Ibrahim, A.Q., Adamu, H.M., Nurudeen, A.A.. Effects of calcium carbonate and Kaolin filler loading on curing rates of polyurethane foams.International research Journal of pure and applied chemistry, 2014, 4(6): 691-694.

[12] Chris-Okafor, P.U., Arinze, R.M., Nwokoye, J.N, Ukpai E.U.. Effects of Coconut husk and Corn cobs as Fillers in Flexible polyurethane foam. American Journal of Polymer Science and Technology, 2017, 3(4): 64-69.

[13] Ruijun, G., Mohini, M.S, Samir, K.K.. A Feasibility Study of Polyurethane Composite Foam with Added Hardwood Pulp, Industrial Crops and Products, Checkmate press, New York, 2013, 42(2): 73-279.

[14] Chris-Okafor, P.U., Arinze, R.U., Ekpunobi, U.E., Anugwom M.C.. Effects of Mixed rice husk and Corn cob as Fillers on Some Properties of Flexible Polyurethane Foam. Global Journal of Science Frontier Research B: Chemistry, 2017, 17(2): 2249-4626.

[15] Onuegbu, T.U.. A Study On the Effects of Coconut and Palm Kernel Shells On Density, Porosity Index and Tensile Properties of Flexible Polyether Foam,ARPN Journal of science and Technology, 2012, 2(6): 529-532.

[16] Billimeyer, F.W.J.R.. Text Book of Polymer Science. New York: John Wiley and Sons. 1984, 246.

[17] Onuegbu, T.U., Ugwu, L.E., Ogunfeyitimi, O.. Physio-mechanical Properties of Flexible Polyether Foam: Comparative effects of fillers, Chemistry and material research, 2013, 3(9): 48.

Downloads

How to Cite

Chris-Okafor, P. U., Arinze, R., Iloamaeke, I., & Izundu, B. C. (2019). Investigation of the Mechanical Properties of Flexible Polyether Foam Filled with Eggshell and Groundnut Husk Powder. Organic Polymer Material Research, 1(2), 14–19. https://doi.org/10.30564/opmr.v1i2.1641

Issue

Vol. 1 , Iss. 2 (December 2019)
