Aims and ScopeA Novel Process for SiGe Core-Shell JAM Transistors Fabrication and Thermal Annealing Effect on Its Electrical Performance
Authors
-
Ashish Kumar
Department of Electrical Engineering, National Cheng Kung University, Taiwan
-
Wen-Hsi Lee
Department of Electrical Engineering, National Cheng Kung University, Taiwan
DOI:
https://doi.org/10.30564/ssid.v1i2.1399Abstract
In this study, we fabricate Si/SiGe core-shell Junctionless accumulationmode (JAM)FinFET devices through a rapid and novel process with fourmain steps, i.e. e-beam lithography definition, sputter deposition, alloycombination annealing, and chemical solution etching. The height of Sicore is 30 nm and the thickness of Si/SiGe core-shell is about 2 nm. Afterfinishing the fabrication of devices, we widely studied the electrical characteristics of poly Si/SiGe core-shell JAM FinFET transistors from a viewof different Lg and Wch. A poly-Si/SiGe core -shell JAMFETs was successfully demonstrated and it also exhibits a superior subthreshold swingof 81mV/dec and high on/off ratio > 105 when annealing for 1hr at 600°C.The thermal diffusion process condition for this study are 1hr at 600°C and6hr at 700°C for comparison. The annealing condition at 700oC for 6 hoursshows undesired electrical characteristics against the other. Results suggeststhat from over thermal budget causes a plenty of Ge to precipitate againstto form SiGe thin film. Annealing JAMFETs at low temperature showsoutstanding Subthreshold swing and better swing condition when compared to its counterpart i.e. at higher temperature. This new process can stillfabricate a comparable performance to classical planar FinFET in drivingcurrent.Keywords:
Junctionless-accumulation (JAM) FET; Junctionless (JL) FET; SiGe core-shell; Rapid thermal anneal Subthreshold swing (SS)References
[1] Xiang, J., et al.. Ge/Si nanowire heterostructures as high-performance field-effect transistors. nature, 2006, 441(7092): 489.
[2] Jiang, Y., et al.. Omega-gate p-MOSFET with nanowirelike SiGe/Si core/shell channel. IEEE Electron Device Letters, 2009, 30(4): 392-394.
[3] Hashemi, P., et al.. Width-dependent hole mobility in top-down fabricated Si-core/Ge-shell nanowire metal-oxide-semiconductor-field-effect-transistors. Applied Physics Letters, 2010, 96(6): 063109.
[4] Woo Lee, J., et al.. Short channel mobility analysis of SiGe nanowire p-type field effect transistors: Origins of the strain induced performance improvement. Applied Physics Letters, 2012, 101(14): 143502.
[5] Schmidt, V., et al.. Silicon nanowires: a review on aspects of their growth and their electrical properties. Advanced Materials, 2009, 21(25-26): 2681-2702.
[6] David, T., et al.. Tailoring Strain and Morphology of Core–Shell SiGe Nanowires by Low-Temperature Ge Condensation. Nano letters, 2017, 17(12): 7299-7305.
[7] Pham, D., L. Larson, J.-W. Yang. FinFET device junction formation challenges. in 2006 International Workshop on Junction Technology. IEEE, 2006.
[8] Lee, C.-W., et al.. Junctionless multigate field-effect transistor. Applied Physics Letters, 2009, 94(5): 053511.
[9] Lee, C.-W., et al.. Performance estimation of junctionless multigate transistors. Solid-State Electronics, 2010, 54(2): 97-103.
[10] Colinge, J.-P., et al.. Nanowire transistors without junctions. Nature nanotechnology, 2010, 5(3): 225.
[11] Kim, T.K., et al.. First demonstration of junctionless accumulation-mode bulk FinFETs with robust junction isolation. IEEE Electron Device Letters, 2013, 34(12): 1479-1481.
[12] Kranti, A., et al. Junctionless nanowire transistor (JNT): Properties and design guidelines. in 2010 Proceedings of the European Solid State Device Research Conference. IEEE, 2010.
[13] Han, M.-H., et al.. Device and circuit performance estimation of junctionless bulk FinFETs. IEEE Transactions on Electron Devices, 2013, 60(6): 1807-1813.
[14] Park, C.-H., et al.. Electrical characteristics of 20-nm junctionless Si nanowire transistors. Solid-State Electronics, 2012, 73: 7-10.
[15] Leung, G. C.O. Chui, Variability impact of random dopant fluctuation on nanoscale junctionless FinFETs. IEEE Electron Device Letters, 2012, 33(6): 767-769.
[16] Rios, R., et al.. Comparison of junctionless and conventional trigate transistors with $ L_ {g} $ down to 26 nm. IEEE electron device letters, 2011, 32(9): 1170-1172.
[17] Jeon, D.-Y., et al.. Low-temperature electrical characterization of junctionless transistors. Solid-State Electronics, 2013, 80: 135-141.
[18] Hashemi, P., et al.. High-mobility high-Ge-content Si 1− x Ge x-OI PMOS FinFETs with fins formed using 3D germanium condensation with Ge fraction up to x~ 0.7, scaled EOT~ 8.5 Å and ~ 10nm fin width. in 2015 Symposium on VLSI Circuits (VLSI Circuits), IEEE, 2015.
[19] Adhikari, H., et al.. High mobility SiGe shell-Si core omega gate pFETS. in 2009 International Symposium on VLSI Technology, Systems, and Applications. IEEE, 2009.
[20] Sioncke, S., et al.. Etch rates of Ge, GaAs and InGaAs in acids, bases and peroxide based mixtures. ECS Transactions, 2008, 16(10): 451-460.
[21] Huygens, I.M., W.. Gomes, and K. Strubbe, Etching of germanium in hydrogenperoxide solutions. ECS Transactions, 2007, 6(2): 375-386
