Experimental Study on the Influence of Date Palm Fibers Reinforced Bituminous Mixtures
Authors
-
Saci Abdelhakim Ferkous
Civil Engineering Department, Faculty of Technology, University M’Hamed Bougara, Boumerdes 35000, Algeria
-
Kahlouche Ramdane
Public Works Department, Faculty of Technology, University Mouloud Mammeri Tizi-Ouzou, Tizi Ouzou 15000, Algeria
DOI:
https://doi.org/10.30564/jbms.v7i3.8910Abstract
This study investigates the influence of date palm fibers (DPF) on the mechanical performance of bituminous mixtures using two experimental methodologies: the wet and dry processes. In the wet process, DPFs were pre-blended with bitumen at varying contents ranging from 1% to 5% by weight, prior to mixing with aggregates. The resulting mixtures were evaluated based on several key performance indicators, including Marshall stability, creep resistance, compactness, and water sensitivity. The inclusion of fibers generally enhanced mechanical properties, with optimal improvements observed at 2% to 4% fiber content. Notably, the mixture with 3% DPF content demonstrated a 35.7% increase in Marshall stability, while the lowest compactness reduction (−1.9%) occurred at 1% fiber addition. In the dry process, the effects of both fiber length (1 cm, 3 cm, and 5 cm) and fiber content (0.1% to 0.5%) were examined, focusing specifically on rutting and creep resistance. The results showed that 3 cm fibers significantly improved rutting resistance, whereas the 0.1% fiber content yielded the highest enhancement in creep resistance. However, no clear correlation was established between the two performance metrics, suggesting that the mechanical response is highly deformation-dependent. Overall, the addition of DPF contributed to improved durability, strength, and resistance to deformation in asphalt mixtures. The findings underscore the potential of date palm fibers as a sustainable, low-cost, and environmentally friendly additive in pavement engineering, particularly in regions where palm waste is readily available and underutilized.
Keywords:
Date Palm Fibers; Creep Behavior; Rutting Resistance; Oedometric Apparatus; Sustainable DevelopmentReferences
[1] Brown, E.R., Cross, S.A., 1992. A Study of In-Place Rutting of Asphalt Pavements. Asphalt Paving Technology Proceedings. 61, 535–577.
[2] Huang, Y.H., 2004. Pavement Analysis and Design, 2nd ed. Pearson Prentice Hall: Upper Saddle River, NJ, USA.
[3] Roberts, F.L., Kandhal, P.S., Brown, E.R., et al., 1996. Hot Mix Asphalt Materials, Mixture Design, and Construction. National Asphalt Pavement Association Research and Education Foundation: Lanham, MD, USA.
[4] Airey, G.D., 2003. Rheological Characteristics of Polymer Modified and Aged Bitumens. Fuel. 82(14), 1709–1719. DOI: https://doi.org/10.1016/S0016-2361(03)00146-7
[5] Fahad, M., Nagy, R., 2025. Performance Comparison of Polymer and Fiber Modified Asphalt Mixtures. Discover Applied Sciences. 7, 570. DOI : https://doi.org/10.1007/s42452-025-07134-7
[6] Yildirim, Y., 2007. Polymer Modified Asphalt Binders. Construction and Building Materials. 21(1), 66–72. DOI: https://doi.org/10.1016/j.conbuildmat.2005.07.007
[7] Attia, M.H., Abdelrahman, M., 2009. Enhancing the Performance of Crumb Rubber-Modified Binders Through Varying Curing Conditions. International Journal of Pavement Engineering. 10(6), 423–434. DOI: https://doi.org/10.1080/10298430802343177
[8] Bellatrache, Y., Ziyani, L., Dony, A., et al., 2022. Study of the Mechanical and Microstructural Properties of Stone Mastic Asphalt Containing Algerian Date Palm Fibers: Influence of the Manufacturing Process. Innovative Infrastructure Solutions. 7, 191. DOI: https://doi.org/10.1007/s41062-022-00794-z
[9] Bellatrache, Y., Ziyani, L., Dony, A., et al., 2020. Effects of the Addition of Date Palm Fibers on the Physical, Rheological and Thermal Properties of Bitumen. Construction and Building Materials. 239, 117808. DOI: https://doi.org/10.1016/j.conbuildmat.2019.117808
[10] Faiad, A., Alsmari, M., Ahmed, M.M.Z., et al., 2022. Date Palm Tree Waste Recycling: Treatment and Processing for Potential Engineering Applications. Sustainability. 14(3), 1134. DOI: https://doi.org/10.3390/su14031134
[11] Mahmood, O.T., Ahmed, S.A., 2020. Influence of Natural Fibers on the Performance of Hot Mix Asphalt for the Wearing Course of Pavement. ARO–The Scientific Journal of Koya University. 8(2), 57–63. DOI: https://doi.org/10.14500/aro.10710
[12] Thomas, B.S., Gupta, R.C., 2015. A Comprehensive Review on the Applications of Waste Tire Rubber in Cement Concrete. Renewable and Sustainable Energy Reviews. 54, 1323–1333. DOI: https://doi.org/10.1016/j.rser.2015.10.092
[13] Parida, S.P., Jena, P.C., Swain, M., et al., 2024. Fabrication of Geopolymer Composites Using Egg-Shell and Fly-Ash: Comparison Between the Strength and Stability, Physio-Chemical and Mechanical Properties. Process Safety and Environmental Protection. 187, 1140–1149. DOI: https://doi.org/10.1016/j.psep.2024.05.020
[14] Parida, S.P., Mishra, D., Padhy, R.L., et al., 2022. Effect of Alkali Treatment on Mechanical and Buckling Behaviour of Natural Fiber Reinforced Composite Cylinder. ES Materials & Manufacturing. 24, 1161. DOI: https://doi.org/10.30919/esmm1161
[15] Takaikaew, T., Hoy, M., Horpibulsuk, S., et al., 2021. Performance Improvement of Asphalt Concretes Using Fiber Reinforcement. Heliyon. 7(5), e07015. DOI: https://doi.org/10.1016/j.heliyon.2021.e07015
[16] Slebi-Acevedo, C.J., Lastra-González, P., Pascual-Muñoz, P., et al. 2019. Mechanical Performance of Fibers in Hot Mix Asphalt: A Review. Construction and Building Materials. 200, 756–769. DOI: https://doi.org/10.1016/j.conbuildmat.2018.12.171
[17] Tapkın, S., Özcan, S., 2012. Determination of the Optimal Polypropylene Fiber Addition to the Dense Bituminous Mixtures by the Aid of Mechanical and Optical Means. The Baltic Journal of Road and Bridge Engineering. 7(3), 169–178. DOI: https://doi.org/10.3846/bjrbe.2012.03
[18] Moghaddam, T.B., Karim, M.R., Syammaun, T., 2012. Dynamic Properties of Stone Mastic Asphalt Mixtures Containing Waste Plastic Bottles. Construction and Building Materials. 34, 236–242. DOI: https://doi.org/10.1016/j.conbuildmat.2012.02.054
[19] Wu, M.M., Li, R., Zhang, Y.Z., et al., 2015. Stabilizing and Reinforcing Effects of Different Fibers on Asphalt Mortar Performance. Petroleum Science. 12(1), 189–196. DOI: https://doi.org/10.1007/s12182-014-0011-8
[20] Singh, S., Parida, S.P., Ekka, P., et al., 2019. Characterization of Fabricated FG Pipe with Natural Fiber-Fly Ash-Epoxy Using Centrifugal Casting. International Journal of Innovative Technology and Exploring Engineering. 8(11), 734–741.
[21] Parida, S.P., Jena, P.C., 2023. Multi-Fillers GFRP Laminated Composite Plates: Fabrication & Properties. Journal of Engineering and Materials Sciences (IJEMS). 29(6), 817–825.
[22] Parida, S.P., Jena, P.C., Das, S.R., et al., 2024. Transverse Vibration of Laminated Composite Plates with Fillers Under Moving Mass Rested on Elastic Foundation Using Higher Order Shear Deformation Theory. Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science. 238(20), 9878–9888. DOI: https://doi.org/10.1177/09544062241256589
[23] Islam, M., Akil, H.M., Jawaid, M., et al., 2021. Critical Review of Natural Fiber Reinforced Hybrid Composites: Processing, Properties, Applications and Cost. Polymers. 13(20), 3514. DOI: https://doi.org/10.3390/polym13203514
[24] Alagesan, P.K., 2020. Recent Advances of Hybrid Fiber Composites for Various Applications. In: Khan, A., Rangappa, S.M., Jawaid, M., et al. (eds.). Hybrid Fiber Composites: Materials, Manufacturing, Process Engineering. John Wiley & Sons: Weinheim, Germany. pp. 381–404. DOI: https://doi.org/10.1002/9783527824571.ch18
[25] Haris, N.I.N., Hassan, M.Z., Ilyas, R.A., et al., 2022. Dynamic Mechanical Properties of Natural Fiber Reinforced Hybrid Polymer Composites: A Review. Journal of Materials Research and Technology. 19, 167–182. DOI: https://doi.org/10.1016/j.jmrt.2022.04.155
[26] Organisme de Contrôle Technique des Travaux Publics (CTTP). 2004. Recommendations on the Use of Bitumens and Hot Mix Asphalts. Ministère des Travaux Publics: Algiers, Algeria. (in French)
[27] Al-Hadidy, A.I., Tan, Y.Q., 2009. Mechanistic Approach for Polypropylene-Modified Flexible Pavements. Materials & Design. 30(4), 1133–1140. DOI: https://doi.org/10.1016/j.matdes.2008.06.021
[28] Wu, S., Ye, Q., Li, N., et al., 2008. Effects of Fibers on the Dynamic Properties of Asphalt Mixtures. Journal of Wuhan University of Technology—Materials Science. 22, 733–736. DOI: https://doi.org/10.1007/s11595-006-4733-3
[29] EN 12697-34, 2012. Bituminous Mixtures – Test Methods for Hot Mix Asphalt – Part 34: Marshall Test. European Committee for Standardization (CEN): Brussels, Belgium.
[30] Association Française de Normalisation (AFNOR), 2002. NF P 98-251-1: Static Tests on Hydrocarbon Mixtures – Part 1: Duriez Test on Hot Mix Asphalts. Association Française de Normalisation: Paris, France. (in French)
[31] EN 12697-46, 2020. Bituminous Mixtures – Test Methods – Part 46: Cracking and Low-Temperature Properties by Uniaxial Tensile Tests. European Committee for Standardization (CEN): Brussels, Belgium.
[32] EN 12697-22, 2020. Bituminous Mixtures – Test Methods – Part 22: Wheel Tracking Test. European Committee for Standardization (CEN): Brussels, Belgium.
Downloads
How to Cite
Ferkous, S. A., & Ramdane, K. (2025). Experimental Study on the Influence of Date Palm Fibers Reinforced Bituminous Mixtures. Journal of Building Material Science, 7(3), 143–165. https://doi.org/10.30564/jbms.v7i3.8910
