Bearing Capacity of Defective Reinforced Concrete Pile in Sand-model Study

Authors

  • A. M. Nasr Geotechnical Engineering, Faculty of Engineering, Tanta University, Tanta, Egypt
  • W. R. Azzam Geotechnical Engineering, Faculty of Engineering, Tanta University, Tanta, Egypt
  • K. E. Ebeed Faculty of Engineering, Tanta University, Tanta, Egypt

DOI:

https://doi.org/10.30564/agger.v4i3.4808

Abstract

Concrete piles that were poorly constructed or analyzed in their soil analyses may have structural or geotechnical defects. To examine such defects, an experimental study was conducted to investigate how a defective reinforced concrete pile behaved. These piles were installed and subjected to a compression axial load in the sand that had relative densities of 30%,60%, and 80%. The tests were performed using four concrete model piles: one intact pile and the other three piles had a structural defect (necking) at three different positions of the pile at (0.25 L from the top, center, and 0.25 L bottom). Geotechnical defect (soft layer or debris) was studied using Styrofoam layer at various vertical distances under the pile toe with Y/D = (0, 0.5, 1 and 1.5) D. The test results showed that the bearing capacity of the structural defect was the most in the case of a neck at 0.25 L from the bottom, followed by a neck at the center, and finally a neck at 0.25 L from the top. In the case of a geotechnical defect, the bearing capacity of the pile decreased with the decrease of the vertical distance between the soft layer and the pile toe.

Keywords:

Structural defect; Geotechnical defect; Debris; Necking and soft layer

References

[1] Poulos, H.G., 2005. Pile behavior—Consequences of geological and construction imperfections. Journal of Geotechnical and Geoenvironmental Engineering. 131(5), 538-563. DOI: https://doi.org/10.1061/(ASCE)1090-0241(2005)131:5(538)

[2] Poulos, H.G., 1999. Behaviour of pile groups with defective piles. International Conference on Soil Mechanics and Foundation Engineering. pp. 871-876.

[3] Klingmüller, O., Kirsch, F., 2004. A Quality and Safety Issue for Cast-in-Place Piles-25 Years of Experience with Low-Strain Integrity Testing in Germany: From Scientific Peculiarity to Day-to-Day Practice. Current Practices and Future Trends in Deep Foundations. pp. 202-221. DOI: https://doi.org/10.1061/40743(142)12

[4] Sakr, M., 2000. “Load Transfer Characteristics of Model Defective Piles in Clay” 8ASEC. pp. 1037-1051.

[5] Al-Mosawe, M., Al-Shakarchi, Y., 2021. Behavior of Defective Cast in Place Piles. Journal of Engineering. 27(4). DOI: https://doi.org/10.31026/j.eng.2021.04.08

[6] Eslami, A., Fellenius, B.H., 1997. Pile capacity by direct CPT and CPTu methods applied to 102 case histories. Canadian Geotechnical Journal. 34(6), 886- 904. DOI: https://doi.org/10.1139/t97-056

[7] Elsawwaf, M.A.E., Azzam, W.R., Kassem, E.M., 2021. An Experimental Study of the Behavior of a Strip Footing Adjacent to Reinforced Sand Slope Above a Soft Pocket. GEOMATE Journal. 21(87), 118-127. DOI: https://doi.org/10.21660/2021.87.j2369

[8] Xu, M., Ni, P., Ding, X., et al., 2019. Physical and numerical modelling of axially loaded bored piles with debris at the pile tip. Computers and Geotechnics. 114, 103146. DOI: https://doi.org/10.1016/j.compgeo.2019.103146

[9] Azzam, W.R., Al Mesmary, M., 2010. The behavior of single tension pile subjected to surcharge loading. Ned University Journal of Research. 7(1), 1-12.

[10] ECP (Egyptian Code of Practice), 2007. Egyptian code for design and construction of reinforced concrete structures. ECP 203-2007, Housing and Building Research Centre, Cairo.

[11] American Concrete Institute, 2000. Design, Manufacture, and Installation of Concrete Piles (ACI 543R-00), American Concrete Institute, Michigan, USA.

[12] Rao, S., Nasr, A., 2010. Behavior of vertical piles embedded in reinforced sand under pullout oblique loads. International Journal of Geotechnical Engineering. 4(2), 217-230. DOI: https://doi.org/10.3328/IJGE.2010.04.02.217-230

[13] IS 2911 Part 1/Sec 1, 2010. Indian standard design and construction of pile foundations-code of practice: concrete piles.

[14] Terzaghi, K., Peck, R.B., Mesri, G., 1996. Soil mechanics in engineering practice. John Wiley & Sons.

[15] Meyerhof, G.G., 1976. Bearing capacity and settlement of pile foundations. Journal of the Geotechnical Engineering Division. 102(3), 197-228. DOI: https://doi.org/10.1061/AJGEB6.0000243

[16] Krishnamurthy, P., Hariswaran, S., 2017. Numerical Studies on the Load Carrying Capacity of Defective Pile. Indian Geotechnical Conference.

[17] Sarvesh, E.A., Hariswaran, S., Premalatha, K. Influence of presence of defective pile in the load carrying capacity of pile group. Indian Geotechnical Conference.

Downloads

How to Cite

Nasr, A. M., Azzam, W. R., & Ebeed, K. E. (2022). Bearing Capacity of Defective Reinforced Concrete Pile in Sand-model Study. Advances in Geological and Geotechnical Engineering Research, 4(3), 1–11. https://doi.org/10.30564/agger.v4i3.4808
